Trooper SA3100 Level IIIA Soft Armor Panel set

$486.00

Price is for a SET of 2 panels - Front and Back

The SA3100 Level IIIA Soft armor panel provides excellent protection against handgun rounds at a price point most individuals and small agencies can afford.

It is designed to work with the Trooper ACAP-RESCUE and CAP-RESCUE Plate carriers, but will fit a variety of other similarly sized units.

  • NIJ Standard 0101.06 Certified: Tested and verified to meet or exceed ballistic resistance as specified under NIJ Standard 0101.06
  • Aerial Density: 1.32 psf (6.44 kg/sqm)
  • Thinness: 0.287’’
  • Material: Enhanced blend of woven and unidirectional aramid fibers
  • Multi-hit capabilities
  • Sonobond Sealed ripstop water resistant cover
  • Custom sizing: Available for minimum quantity +20% surcharge per size.
  • Warranty: 5 years on all ballistic material and 1 year on exterior cover material and workmanship
WEAPON TYPES
CARTRIDGE PROJECTILE VEL (ft/s ± 30) VEL (m/s ± 9)
.357 SIG (NIJ06) 125 gr FMJ 1470 448
.44 Magnum (NIJ06) 240 gr SJHP 1430 436
.357 Magnum 158 gr JSP 1430 435
.44 Magnum 240 gr SWCGC 1400 426
9 x 19 mm Parabellum 124 gr FMJ RN 1400 426
40 S&W 180 gr FMJ 1155 352

SPECIAL THREATS
CARTRIDGE PROJECTILE VELOCITY
9mm SXT 9-mm +P+, 127-grain SXT 1360 fps / 415 ms
.40 Cal GDHP .40-cal., 165-grain S+W Speer GDHP 1279 fps / 390 ms
5.7 x 28mm SS195

5.70 x 28-mm,

27-grain SS195 LFHP

 2041 fps / 622 ms
5.7 x 28mm SS197

5.70 x 28-mm,

40-grain Hornady V-Max Blue Tip

 1815 fps / 553 ms
