QUANTUM Controller

The Quantum LifeWarmer Controller is the command center of the Quantum Blood and Fluid Warming System. It contains the microprocessor and control algorithm that continually assesses temperature input from tubing thermistors and regulates the energy provided to the tubing heating elements in the proximal and/or distal segments to reach and maintain temperature between 100.4°F (38°+/- 2°C) at patient delivery.

The Controller receives power when connected to the Battery and modulates the energy flow to the TIS/TTS-B. The Quantum Controller has two connections, one for the battery and one for the Thermal Tubing of choice. The connection to the battery is an omni-directional plug for ease of insertion and the connection is safe and secure. The connection to the TIS or TTS-B is bi-directional and simple to execute- it’s plug and play.

The Controller has LED lights on the shoulder of the device to inform the user about the output temperature and flow of the fluid. It will visually alert the care provider to the status of the system.

The Controller is reusable and comes fitted with a Jacket that permits the mating (connection) of the TIS or TTS-B Life Warmer tubing circuit connector to the connector slot on the Controller.

Specs:

• Moderates the energy flow from the Quantum Battery to the Thermal Tubing
• Designed for ease of connecting and durability
• Colored LED lights constantly show during administration of blood/fluid to show status
• Extremely lightweight and durable
• IP53 rated for dust and water resistance with jacket
• Minimum service life - 1000 insertions/removals

Dimensions:

• Controller Body: W 1.25 in. x H 3 in. x D 0.75 in.
• Controller Total Length: 51.25 in.
• Weight (Controller only): 2.5 oz
• Packaged Weight: 5 oz
