SKU: MEDTAC1061

Type: IV/IO Device

Vendor: SAM Medical

SAM IO Driver Adaptor

Name: SAM IO Driver Adaptor
Brand: SAM Medical
SKU: MEDTAC1061
Price: 12.75 USD
Availability: InStock

MARCH PROTOCOL Built around MARCH. Evidence-based trauma care sequence →

Your Price: $12.75

Ships from Florida HQ Free Shipping $200+ CONUS Free APO/FPO Shipping 30-Day Unopened Returns

$12.75

PRODUCT INFORMATION

SAM Medical · IO Access Component

SAM IO Driver Adaptor

The Luer-lock adaptor that closes out a SAM IO placement. Once the needle is seated and the stylet withdrawn, the adaptor connects the catheter to a standard extension set, syringe or IV line for aspiration, flush and infusion. A single 2.5 oz component of the battery-free SAM IO system — driver and needles sold separately.

Standard Luer-lock2.5 ozSAM IO system componentMFR IO742-EN

A seated IO needle is not yet access. The adaptor is the piece between a correct placement and fluid actually moving.

What's Included

Single configuration. This listing is the adaptor alone. Tap to see what ships.

VIEW ▾What's Included — SKU MEDTAC1061

1× SAM IO Driver Adaptor — standard Luer-lock extension adaptor for the SAM IO Intraosseous Access System
MED-TAC SKU MEDTAC1061 · manufacturer part IO742-EN · 2.5 oz
Not included: The SAM IO Driver, SAM IO needles (15 mm / 25 mm / 45 mm) and the SAM IO Stabilizer — all sold separately

▾Specifications

SAM IO Driver Adaptor — specifications

Specification	Detail
Manufacturer	SAM Medical
SKU (MED-TAC)	MEDTAC1061
Manufacturer part number	IO742-EN
Weight	2.5 oz
Connection type	Standard Luer-lock
Function	Connects the placed IO catheter to a standard extension set, syringe or IV line for aspiration verification, flush and infusion
Position in the workflow	After needle placement and stylet removal — the last step before treatment begins
Compatible system	SAM IO Driver and SAM IO needles (both sold separately)
Related SAM IO components	SAM IO Driver (30-0255) · needles in 15 mm, 25 mm and 45 mm · Stabilizer (MEDTAC1059 / MEDTAC1060)
Power	None — the SAM IO system is manually operated and battery-free, so there is nothing on this component to charge or fail
Clinical evaluation	No evidence-based evaluation applies. evidence-based evaluations attach to clinical interventions and the devices delivering them; this is a connection component within an IO system.

Intraosseous access is an invasive procedure performed under scope of practice and medical direction. This page describes a system component and its published specifications; insertion site selection and technique are covered by the manufacturer's instructions for use and by accredited training, not by this page.

▾Who Carries It

Combat medics, SOF medical providers, paramedics, flight crews and emergency clinicians already fielding the SAM IO system · Unit and agency logistics restocking the adaptor as a consumable alongside needles · Kit builders assembling a complete IO module, where the adaptor is the component most often discovered missing at the wrong moment.

This is a component, not a standalone capability — it is only useful to a provider who already carries a SAM IO Driver and needles and is authorized to establish intraosseous access. The manufacturer describes IO access as an option for adult and paediatric patients when peripheral IV access cannot be rapidly established; whether and when to use it is a protocol and scope-of-practice decision.

Genuine SAM Medical

Sourced direct from the manufacturer or an authorized master distributor. Ships from MED-TAC International, Pembroke Pines, FL — clinician-founded, veteran-led, SDVOSB-certified.

Built around MARCH. Every kit we sell maps to the MARCH protocol — Massive hemorrhage, Airway, Respiration, Circulation, Hypothermia. Learn the sequence in our complete MARCH guide.

SPECS & MEASUREMENTS

Specifications coming soon. Contact us for detailed product information.

SHIPPING & RETURNS

Domestic & Military Shipping

Free Standard Shipping: Automatically applied at checkout on all orders $200 and above within the 48 contiguous United States (CONUS).

APO/FPO Military Addresses: Unconditionally free standard shipping on every order, with no minimum purchase required.

Order Processing & Tracking

Standard Gear: In-stock medical devices, consumables, and tactical packs process within 48 hours.

Stocked Kit Bags: Custom-built kits ship within 7-10 days as they are assembled by hand at our South Florida facility.

Automated carrier tracking details are emailed immediately upon shipment dispatch.

30-Day Returns & Medical Safety

Returns: Unused, unopened equipment in original manufacturer packaging is eligible for return within 30 days of delivery.

Bio-Safety Notice: To ensure sterility and patient safety, medical consumables with opened or broken tamper-evident seals cannot be returned.

Return Facility: MED-TAC International Corp., 15757 Pines Blvd, Suite 154, Pembroke Pines, FL 33027.

Export Compliance

North American Rescue (NAR) products and rifle hard armor plates are strictly restricted to US and APO/FPO addresses and cannot be exported internationally.

FREQUENTLY ASKED QUESTIONS

What does the SAM IO Driver Adaptor do?

The SAM IO Driver Adaptor (MEDTAC1061) is the Luer-lock connection piece that attaches to the SAM IO catheter hub after the stylet is removed following successful IO needle placement. It provides a standard Luer-lock interface for connecting an extension set, syringe, or IV administration line, enabling aspiration verification (to confirm intraosseous placement), flushing, and delivery of fluids or medications via the IO route.

Is the Adaptor included with the SAM IO Driver?

The SAM IO Intraosseous Access System full kit includes a driver, three needle sizes (15 mm, 25 mm, 45 mm), a Stabilizer, and an Adaptor. However, if purchasing the SAM IO Driver (30-0255) individually, the Adaptor may be sold separately as a standalone replacement or additional item under SKU MEDTAC1061 (manufacturer part IO742-EN). Always verify your kit configuration to ensure you have the Adaptor before attempting IO access.

What type of connection does the SAM IO Adaptor use?

The SAM IO Adaptor uses a standard Luer-lock connection, which is the universal fitting used on most IV extension sets, syringes, and infusion lines in medical practice. This allows the SAM IO system to interface with any standard Luer-lock compatible extension set for fluid or medication delivery without requiring proprietary connectors beyond the adaptor itself.

Can the SAM IO Adaptor be used with other IO systems?

The SAM IO Adaptor is specifically designed for use with the SAM IO Intraosseous Access System and its needle/catheter assemblies. It is not interchangeable with EZ-IO, FAST-1, or other IO systems that use different catheter hub designs. For IO access via other platforms, use the adaptors or extension sets designed for those specific systems.

Which SAM IO components do I need for a complete IO access kit?

A complete SAM IO access kit requires: the SAM IO Driver (30-0255) for needle placement; one or more SAM IO Needle assemblies in the appropriate size (15 mm for pediatric/thin adults, 25 mm for standard adults, 45 mm for obese patients or proximal humerus); the SAM IO Stabilizer (MEDTAC1059) to prevent catheter dislodgement; and the SAM IO Adaptor (MEDTAC1061) for connecting to an extension set. Each sterile-packed needle also includes a NeedleVISE® sharp containment device and extension tube.
